IKO LRT606835
Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with TAF688235
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRT606835
Shaft Dimaeter
60
mm
Inside Diamater
60
mm
Outer Diameter
68
mm
Width
35
mm
rs min.
0.60
mm
da min
64.0
mm
da max
66.0
mm
Assembled bearings
TAF 688235
Assembled bearings
-
Assembled bearings
-
Assembled bearings
-
Mass
210.0
g
The IKO LRT606835 Is a Metric Inner Ring
What are the basic identifying details of the LRT606835?
The LRT606835 is an IKO inner ring within the Inner Rings product series. It is listed under the category path Brand > IKO > Inner Rings and is described for assembly with TAF688235.
- Order number: LRT606835
- Brand: IKO
- Bearing type: Inner Rings
- Designation: Metric
The LRT606835 Has Defined Bore, Outside Diameter, and Width Dimensions
What dimensions are provided for this inner ring?
The supplied product data lists the following measurements for the IKO LRT606835:
- Shaft diameter / inside diameter: 60 mm
- Outer diameter: 68 mm
- Width: 35 mm
- rs minimum: 0.60 mm
- da minimum: 64.0 mm
- da maximum: 66.0 mm
The LRT606835 Uses High Carbon Steel and Has a Stated Mass
What material and assembly information is available?
The bearing material is listed as High Carbon Chrome Steel, while the title description identifies the inner ring material as high carbon steel. The product is intended to assemble with TAF 688235, also referenced as TAF688235. The stated mass is 210.0 g.
- Material: High Carbon Chrome Steel
- Assembled bearing reference: TAF 688235
- Mass: 210.0 g
