IKO NAST10ZZUU
Roller Follower, Metric, Separable Type, Caged, High Carbon Chrome Steel, Oil Hole, Sealed, Cylindrical
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAST10ZZUU
Shaft diameter
10
mm
Inside diameter
10
mm
Outer Diameter
30
mm
Width
16
mm
Width
15.8
mm
Diameter
23.5
mm
Chamfer
2.5
mm
Chamfer
0.8
mm
Basic dynamic load diameter
9790
mm
Basic static load rating
9680
mm
Mass
65.0
g
