IKO NAST12R
Roller Follower, Metric, Separable Type, Caged, High Carbon Chrome Steel, Open, Crowned
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAST12R
Shaft diameter
12
mm
Inside diameter
12
mm
Outer Diameter
32
mm
Width of innerring
12
mm
Width
11.8
mm
rs min.
0.0
mm
r1s min
0.3
mm
Inscribed circle diameter
16
mm
Basic dynamic load rating
10500
N
Basic static load rating
10900
N
Type of Inner Ring
LRT 121612S
Mass
58.0
g
