IKO NAST20R
Roller Follower, Metric, Separable Type, Caged, High Carbon Chrome Steel, Open, Crowned
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAST20R
Shaft diameter
20
mm
Inside diameter
20
mm
Outer Diameter
47
mm
Width of innerring
16
mm
Width
15.8
mm
rs min.
0.0
mm
r1s min
0.3
mm
Inscribed circle diameter
25
mm
Basic dynamic load rating
19400
N
Basic static load rating
24500
N
Type of Inner Ring
LRT 202516S
Mass
157.0
g
