IKO NAST40
Roller Follower, Metric, Separable Type, Caged, High Carbon Chrome Steel, Open, Cylindrical
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAST40
Shaft diameter
40
mm
Inside diameter
40
mm
Outer Diameter
80
mm
Width of innerring
20
mm
Width
19.8
mm
rs min.
1.5
mm
r1s min
1.0
mm
Inscribed circle diameter
50
mm
Basic dynamic load rating
35900
N
Basic static load rating
61100
N
Type of Inner Ring
LRT 405020S
Mass
530.0
g
