IKO NAST45R
Roller Follower, Metric, Separable Type, Caged, High Carbon Chrome Steel, Open, Crowned
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAST45R
Shaft diameter
45
mm
Inside diameter
45
mm
Outer Diameter
85
mm
Width of innerring
20
mm
Width
19.8
mm
rs min.
0.0
mm
r1s min
1.0
mm
Inscribed circle diameter
55
mm
Basic dynamic load rating
37400
N
Basic static load rating
66400
N
Type of Inner Ring
LRT 455520S
Mass
580.0
g
