IKO NATB5910
Combined with Three Point Contact Ball Bearing
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NATB5910
Shaft Diameter
50
mm
Inside Diameter
50
mm
Outside Diameter
72
mm
Width
30
mm
Width of innerring
34
mm
rs min.
0.6
mm
Inscribed circle diameter
58
mm
da min
54
mm
Da max
68
mm
Basic dynamic load rating (Radial)
33600
N
Basic dynamic load rating (Axial)
5660
N
Basic static load rating (Radial)
72500
N
Basic static load rating (Axial)
13600
N
Mass
445.0
g
