IKO NATB5912
Combined with Three Point Contact Ball Bearing
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NATB5912
Shaft Diameter
60
mm
Inside Diameter
60
mm
Outside Diameter
85
mm
Width
34
mm
Width of innerring
38
mm
rs min.
1.0
mm
Inscribed circle diameter
68
mm
da min
65
mm
Da max
80
mm
Basic dynamic load rating (Radial)
41800
N
Basic dynamic load rating (Axial)
10700
N
Basic static load rating (Radial)
82200
N
Basic static load rating (Axial)
26700
N
Mass
660.0
g
