IKO NAX7040
Combined with Thrust Ball Bearing W/o Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NAX7040
Shaft Diameter
70
mm
Inscribed circle diameter
70
mm
Outside Diameter
85
mm
Outside Diameter
95
mm
Outside Diameter
0.0
mm
Width
40
mm
Width
18
mm
Dimension
11.0
mm
rs min.
1.0
mm
Inside Diameter
70
mm
da min
85
mm
Basic dynamic load rating (Radial)
55500
N
Basic dynamic load rating (Axial)
43100
N
Basic static load rating (Radial)
120000
N
Basic static load rating (Axial)
101000
N
Mass
555.0
g
