IKO NAX7040Z
Combined with Thrust Ball Bearing, W/o Inner Ring, With Dust Cover
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NAX7040Z
Shaft Diameter
70
mm
Inscribed circle diameter
70
mm
Outside Diameter
85
mm
Outside Diameter
95
mm
Outside Diameter
96.5
mm
Width
40
mm
Width
18
mm
Dimension
11.0
mm
rs min.
1.0
mm
Inside Diameter
70
mm
da min
85
mm
Basic dynamic load rating (Radial)
55500
N
Basic dynamic load rating (Axial)
43100
N
Basic static load rating (Radial)
120000
N
Basic static load rating (Axial)
101000
N
Mass
606.0
g
