IKO NAXI4032
Combined with Thrust Ball Bearing With Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NAXI4032
Shaft Diameter
40
mm
Inside Diameter
40
mm
Outside Diameter
58
mm
Outside Diameter
65
mm
Outside Diameter
0
mm
Width
32
mm
Width of innerring
20.0
mm
Width
14
mm
Dimension
9.0
mm
rs min.
0.6
mm
r1s min
0.3
mm
Inscribed circle diameter
45
mm
Inside Diameter
45
mm
da min
57
mm
Dimension related to the installation
44
mm
Basic dynamic load rating (Radial)
31000
N
Basic dynamic load rating (Axial)
27900
N
Basic static load rating (Radial)
60200
N
Basic static load rating (Axial)
55100
N
Type of Inner Ring
LRT 404520
Mass
315.0
g
