IKO NBX1725
Combined with Thrust Roller Bearing, W/o Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NBX1725
Shaft Diameter
17
mm
Inscribed circle diameter
17
mm
Outside Diameter
26
mm
Outside Diameter
30
mm
Outside Diameter
0.0
mm
Width
25
mm
Width
9
mm
Dimension
8.0
mm
rs min.
0.3
mm
Inside Diameter
17
mm
da min
28
mm
Basic dynamic load rating (Radial)
12900
N
Basic dynamic load rating (Axial)
11400
N
Basic static load rating (Radial)
16300
N
Basic static load rating (Axial)
28600
N
Mass
61.0
g
