IKO NBX4032
Combined with Thrust Roller Bearing, W/o Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NBX4032
Shaft Diameter
40
mm
Inscribed circle diameter
40
mm
Outside Diameter
52
mm
Outside Diameter
60
mm
Outside Diameter
0.0
mm
Width
32
mm
Width
13
mm
Dimension
10.0
mm
rs min.
0.6
mm
Inside Diameter
40
mm
da min
57
mm
Basic dynamic load rating (Radial)
29400
N
Basic dynamic load rating (Axial)
41700
N
Basic static load rating (Radial)
54100
N
Basic static load rating (Axial)
133000
N
Mass
240.0
g
