IKO NBX4532
Combined with Thrust Roller Bearing, W/o Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NBX4532
Shaft Diameter
45
mm
Inscribed circle diameter
45
mm
Outside Diameter
58
mm
Outside Diameter
65
mm
Outside Diameter
0.0
mm
Width
32
mm
Width
14
mm
Dimension
9.0
mm
rs min.
0.6
mm
Inside Diameter
45
mm
da min
62
mm
Basic dynamic load rating (Radial)
31000
N
Basic dynamic load rating (Axial)
40800
N
Basic static load rating (Radial)
60200
N
Basic static load rating (Axial)
133000
N
Mass
293.0
g
