IKO SBB10
Spherical Bushing, Inch Series, High Carbon Steel, Steel on Steel, Not Seperable
(BRAND)：IKO
(Availability)：In Stock
Order Number
SBB10
Shaft Diameter
15.875
mm
Inside Diameter
15.88
mm
Outer Diameter
26.99
mm
Width of innerring
13.89
mm
Width
11.91
mm
Diameter
23.0
mm
Min.Radial internal clearance
0.05
mm
Max.Radial internal clearance
0.15
mm
Dimension related to the installation
17.9
mm
ra max
0.2
mm
rb max
0.8
mm
Dynamic load capacity
26900
N
Static load capacity
161000
N
Mass
0.04
kg
