INA CSCC065
Thin Section Bearings
Deep groove ball bearing, Thin section bearing CSCC, brass sheet metal cage
(BRAND)：INA
(Availability)：In Stock
Main Dimensions & Performance Data
d
165.1 mm
Bore diameter
D
184.15 mm
Outside diameter
B
9.525 mm
Width
Cr
9,300 N
Basic dynamic load rating, radial
C0r
13,200 N
Basic static load rating, radial
CG
3,250 1/min
Limiting speed
≈m
310 g
Weight
