INA CSCU060-2RS
Thin Section Bearings
Deep groove ball bearing, Thin section bearing CSCU..-2RS, seals, brass sheet metal cage
(BRAND)：INA
(Availability)：In Stock
Main Dimensions & Performance Data
d
152.4 mm
Bore diameter
D
171.45 mm
Outside diameter
B
12.7 mm
Width
Cr
9,000 N
Basic dynamic load rating, radial
C0r
12,200 N
Basic static load rating, radial
CG
1,700 1/min
Limiting speed
≈m
370 g
Weight
