INA GAR60-UK-2RS
Rod Ends
Rod end with external thread, right hand thread, maintenance-free, sliding layer: ELGOGLIDE, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, sealed
(BRAND)：INA
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d2
135 mm
Outer diameter eye
Cr
691,000 N
Basic dynamic load rating
C0r
405,000 N
Basic static load rating
d
60 mm
Bore diameter bearing
D
90 mm
Outside diameter bearing
l2
277.5 mm
Total length
B
44 mm
Width inner ring
≈m
5.96 kg
Weight
Mounting dimensions
r1s
1 mm
Smallest single chamfer dimension, inner ring
