NSK BSF1560
Double-Row Bearings (BSBD Series)
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
BSF1560
Boundary Dimensions
d
15
mm
Bore diameter
D
60
mm
Outside diameter
B
25
mm
Width
r(min.)
0.6
mm
Chamfer Dimension
r1(min.)
0.3
mm
Chamfer Dimension
Basic Load Ratings
Ca
23.3
kN
Basic Dynamic Load Rating
C0a
26.9
kN
Basic Static Load Rating
Speeds
Grease
7100
min-1
Limiting Speed
Dimensions
60°
Contact Angle
d1
26.7
mm
Shoulder Diameter
D1
35.7
mm
Shoulder/Recess Diameter
Performance
19.4
kN
Limiting Static Axial Load
