NSK BSF1762-DT
Double-Row Bearings (BSBD Series)
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
BSF1762-DT
Boundary Dimensions
d
17
mm
Bore diameter
D
62
mm
Outside diameter
2B
50
mm
Assembled Width
r(min.)
0.6
mm
Chamfer Dimension
r1(min.)
0.6
mm
Chamfer Dimension
Basic Load Ratings
Ca
39.5
kN
Basic Dynamic Load Rating
C0a
59.5
kN
Basic Static Load Rating
Speeds
Grease
6700
min-1
Limiting Speed
Dimensions
60°
Contact Angle
d1
28.1
mm
Shoulder Diameter
D1
37.7
mm
Shoulder/Recess Diameter
Performance
42.5
kN
Limiting Static Axial Load
