NSK BSF2068
Double-Row Bearings (BSBD Series)
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
BSF2068
Boundary Dimensions
d
20
mm
Bore diameter
D
68
mm
Outside diameter
B
28
mm
Width
r(min.)
0.6
mm
Chamfer Dimension
r1(min.)
0.6
mm
Chamfer Dimension
Basic Load Ratings
Ca
31.5
kN
Basic Dynamic Load Rating
C0a
41.0
kN
Basic Static Load Rating
Speeds
Grease
5800
min-1
Limiting Speed
Dimensions
60°
Contact Angle
d1
32.6
mm
Shoulder Diameter
D1
43
mm
Shoulder/Recess Diameter
Performance
29.3
kN
Limiting Static Axial Load
