NTN 51112PX2
Single Direction Thrust Ball Bearing
(BRAND)：NTN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Technical Specifications
Type
Thrust Ball Bearing
Bore Type
Round
Outside Ring Type
Straight
Material
High Carbon Chrome Steel
Cage Type
Pressed
Cage Material
Steel
Ball Material
Steel
Limiting Speed - Oil
3700 RPM
Limiting Speed - Grease
2600 RPM
Seal Type
None
Seal Material
None
Precision
ISO Class 0
Configuration
One
Radial Internal Clearance
CN
Static Load Rating
113000 N
Dynamic Load Rating
41500 N
Enclosure
Open
Weight
0.272 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
60.000 mm
D1
62.000 mm
d1
85.000 mm
D
85.000 mm
T
17.000 mm
r
1.000 mm
