NTN 51206
Single Direction Thrust Ball Bearing
(BRAND)：NTN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Technical Specifications
Type
Thrust Ball Bearing
Bore Type
Round
Outside Ring Type
Straight
Material
High Carbon Chrome Steel
Cage Type
Molded
Cage Material
Resin
Ball Material
Steel
Limiting Speed - Oil
4900 RPM
Limiting Speed - Grease
3400 RPM
Seal Type
None
Seal Material
None
Precision
ISO Class 0
Configuration
One
Radial Internal Clearance
CN
Static Load Rating
58000 N
Dynamic Load Rating
29300 N
Enclosure
Open
Weight
0.129 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
30.000 mm
D1
32.000 mm
d1
52.000 mm
D
52.000 mm
T
16.000 mm
r
0.600 mm
da min
43.000 mm
Da max
43.000 mm
ras max
0.600 mm
