NTN BL317ZNRC3
Single Row Radial Ball Bearings
(BRAND)：NTN
(Availability)：In Stock
Technical Specifications
Type
Deep Groove Ball Bearing
Bore Type
Round
Material
High Carbon Chrome Steel
Cage Type
Pressed
Cage Material
Steel
Ball Material
Steel
Limiting Speed - Oil
4000 RPM
Limiting Speed - Grease
3400 RPM
Precision
ISO Class 0
Configuration
One
Radial Internal Clearance
C3
Enclosure
Single Shielded
Weight
4.780 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
85.000 mm
D
180.000 mm
B
41.000 mm
D1
173.660 mm
D2
192.900 mm
a
5.690 mm
f
3.050 mm
r
3.000 mm
r1
0.500 mm
da min
98.000 mm
da max
112.000 mm
Da max
167.000 mm
ras max
2.500 mm
