NTN BL319ZZC3
Single Row Radial Ball Bearings
(BRAND)：NTN
(Availability)：In Stock
Technical Specifications
Type
Deep Groove Ball Bearing
Bore Type
Round
Material
High Carbon Chrome Steel
Cage Type
Pressed
Cage Material
Steel
Ball Material
Steel
Limiting Speed - Grease
3000 RPM
Seal Type
None
Seal Material
None
Precision
ISO Class 0
Configuration
One
Radial Internal Clearance
CN
Static Load Rating
177900 N
Dynamic Load Rating
200100 N
Enclosure
Double Shielded
Weight
5.900 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
95.000 mm
D
200.000 mm
B
45.000 mm
r
3.000 mm
r1
3.000 mm
