NTN NPC104RP
Eccentric Locking Collar Type Bearings - Cylindrical O.D.
(BRAND)：NTN
(Availability)：In Stock
Technical Specifications
Type
Insert Bearing
Bore Type
Round
Bearing Type
Ball Bearing
Material
Through Hardened Steel
Ball Material
Steel
Limiting Speed - Grease
3150 RPM
Seal Type
Contact
Seal Material
Nitrile Rubber
Performance
Standard Duty
Locking Device
None
Lubrication
Non-Relubricatable
Radial Internal Clearance
C3
Static Load Rating
15300 N
Dynamic Load Rating
25700 N
Enclosure
Double Sealed
Weight
0.585 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
31.750 mm
D
72.000 mm
C
19.000 mm
B
25.400 mm
B1
38.900 mm
r
1.500 mm
S
9.500 mm
r1
1.500 mm
Specifications
Radial Dynamic Load Rating
25700 N
Lubrication
No
Radial Static Load Rating
15300 N
