NTN NPC106RP
Eccentric Locking Collar Type Bearings - Cylindrical O.D.
(BRAND)：NTN
(Availability)：In Stock
Technical Specifications
Type
Insert Bearing
Bore Type
Round
Bearing Type
Ball Bearing
Material
Through Hardened Steel
Ball Material
Steel
Seal Type
Contact
Seal Material
Nitrile Rubber
Performance
Standard Duty
Locking Device
None
Lubrication
Non-Relubricatable
Radial Internal Clearance
C3
Static Load Rating
15300 N
Dynamic Load Rating
25700 N
Enclosure
Double Sealed
Weight
0.535 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
34.925 mm
D
72.000 mm
C
19.000 mm
B
25.400 mm
B1
38.900 mm
r
1.500 mm
S
9.500 mm
r1
1.500 mm
