NTN UCS208LN
Set Screw Type Bearings - Cylindrical O.D.
(BRAND)：NTN
(Availability)：In Stock
Technical Specifications
Type
Insert Bearing
Bore Type
Round
Bearing Type
Ball Bearing
Material
Through Hardened Steel
Ball Material
Through Hardened
Limiting Speed - Grease
3700 RPM
Seal Type
Contact
Seal Material
Nitrile Rubber
Precision Rating
ISO Class 0
Performance
Standard Duty
Locking Device
2 -120° Set Screw
Lubrication
No
Radial Internal Clearance
CN
Static Load Rating
17800 N
Dynamic Load Rating
29100 N
Enclosure
Double Sealed
Weight
3.110 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
40.000 mm
D
80.000 mm
C
21.000 mm
B
49.200 mm
r
1.500 mm
r1
1.500 mm
ds
M8x1
G
8.000 mm
d4
53 mm
S1
30.2 mm
S
19 mm
a
3.4 mm
b
2.05 mm
D1
76.810 mm
Specifications
Radial Dynamic Load Rating
29100 N
Lubrication
No
Radial Static Load Rating
17800 N
