NTN UK311D1
Adapter Type Bearings
(BRAND)：NTN
(Availability)：In Stock
Technical Specifications
Type
Insert Bearing, Adapter Type
Bore Type
Tapered
Bearing Type
Ball Bearing
Material
Through Hardened Steel
Taper
1:12
Seal Type
Contact
Seal Material
Nitrile Rubber
Performance
Intermediate Duty
Locking Device
Adapter
Lubrication
Relubricatable
Static Load Rating
45000 N
Dynamic Load Rating
71500 N
Enclosure
Double Sealed
Weight
2.060 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
55.000 mm
D
120.000 mm
C
34.000 mm
B
44.000 mm
d4
76.600 mm
F
8.500 mm
Bore Size of the Adapter Type H
50.000 mm
Bore Size of the Adapter Type HE
49.213 mm
Bore Size of the Adapter Type HA
47.625 mm
Bore Size of the Adapter Type HS
50.800 mm
