SKF 305807 C-2Z
Cam roller (yoke-type track roller) with crowned outside surface, integral sealing and relubrication feature
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
D
80.0 mm
Outside diameter
d
35.0 mm
Bore diameter
B
27.0 mm
Width
d1
45.4 mm
Shoulder/recess diameter inner ring
D1
63.9 mm
Recess diameter outer ring
R
400.0 mm
Profile running surface (crown) outer ring
r1,2
1.1 mm
Chamfer dimension
a
42.0 mm
Distance pressure points
mass
0.64 kg
Product net weight
