Timken HM535310-B
Tapered Roller Bearings - Single Flanged Cups - Imperial
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
Series
HM535300
Cup Part Number
HM535310-B
Design Units
Imperial
Dimensions
D - Cup Outer Diameter
260.350 mm
D1 - Flange Outer Diameter
271.374 mm
C - Cup Width
52.388 mm
C1 - Cup Flange Width
11.113 mm
Abutment and Fillet Dimensions
r - Cup Backface "To Clear" Radius1
3.30 mm
Da - Cup Frontface Backing Diameter
249.94 mm
Factors
K - Factor2
1.45
e - ISO Factor3
0.4
Y - ISO Factor4
1.49
G1 - Heat Generation Factor (Roller-Raceway)
867
G2 - Heat Generation Factor (Rib-Roller End)
225
Cg - Geometry Factor5
0.124
