Timken LM637349NW – LM637310D
Tapered Roller Bearings - TNA (Tapered Double, non-adjustable) Imperial
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
LM637349NW – LM637310D
Specifications
Cone Part Number
LM637349NW
Cup Part Number
LM637310D
Design Unit
Inch
Dimensions
d - Bore
184.150 mm
D - Cup Outer Diameter
242.888 mm
T - Bearing Width across Cones
95.25 mm
C - Double Cup Width
69.85 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
3.5 mm
r - Cup Backface "To Clear" Radius2
0.8 mm
db - Cone Backface Backing Diameter
199 mm
Da - Cup Frontface Backing Diameter
236 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
80600 N
C1 - Dynamic Radial Rating (1 million revolutions)4
541000 N
C5
57800 N
C906
140000 N
Factors
K - Factor7
1.39
e - ISO Factor8
0.42
Y1 - ISO Factor9
1.61
Y2 - ISO Factor10
2.4
