Timken N 09/SK 4023/N 07/W 07
Push-Type Removable Sleeve, Locknut and Lockwasher
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
Series
223K
Removal Nut O.D. C
64.41 mm
Bearing Number
22308K
Taper
1:30
Shaft Dimensions
Diameter d
35 mm
Tolerance1
-0.08 mm
Adapter Dimensions
Major Diameter
43.94 mm
L2
30 mm
a
3 mm
Accessory Numbers
Removal Nut
N 09
Sleeve
SK 4023
Locknut
N 07
Lockwasher and Lockplates
W 07
