IKO BHA2012ZOH
Shell Needle Roller Bearing, Inch, Caged, Chromium Molybdenum Steel, Heavy Duty
BHA2012ZOH IKO Needle Roller Bearing Overview
The BHA2012ZOH is an IKO shell needle roller bearing in the Needle Roller Bearings product series. It uses a caged internal structure and is made from chromium molybdenum steel according to the supplied product data.
What are the identifying details for this bearing?
The listed order number is BHA2012Z, while the requested model is BHA2012ZOH. The brand is IKO, and the category path places it under Brand > IKO > Needle Roller Bearings.
BHA2012ZOH Dimensions and Specifications
- Shaft diameter: 31.750 mm
- Inscribed circle diameter: 31.750 mm
- Outer diameter: 41.275 mm
- Width: 19.05 mm
- Mass: 49.5 g
- Internal structure: Cage Type
What material and structure are specified?
The bearing material is listed as chromium molybdenum steel, and its internal structure is listed as Cage Type. The supplied description also identifies it as an inch, caged, shell needle roller bearing.
BHA2012ZOH Load Rating Information
The supplied product data lists a basic dynamic load rating of 24,100 N and a basic static load rating of 36,400 N for this needle roller bearing.
What do the listed load ratings indicate?
The values provide the bearing's stated basic dynamic and basic static load ratings in newtons. They can be compared directly with other bearings using the same rating data, without adding unstated performance or application claims.
