IKO KT101410EGB2
Needle Roller Cage for Engine, High Carbon Steel, B2 Tolerance of Roller Dia
(BRAND)：IKO
(Availability)：In Stock
Order Number
KT101410EG
Shaft Diameter
10
mm
Inner Diameter
10
mm
Outer Diameter
14
mm
Width
10.0
mm
Basic dynamic load rating
4900
N
Basic static load rating
4680
N
Mass
3.2
g
IKO KT101410EGB2 Needle Roller Bearing Introduction
What type of bearing is the KT101410EGB2?
The IKO KT101410EGB2 is listed in the Needle Roller Bearings product series and category path Brand > IKO > Needle Roller Bearings. The product introduction describes it as a needle roller cage with a B2 tolerance of roller diameter.
- Brand: IKO
- Model: KT101410EGB2
- Order Number: KT101410EG
- Bearing Type: Needle Roller Bearings
KT101410EGB2 Dimensions and Structure
What dimensions and internal structure are specified?
The supplied data identifies the bearing as having a 10 mm shaft diameter, 10 mm inner diameter, 14 mm outer diameter, and 10.0 mm width. Its listed internal structure is carbon cage type.
- Shaft Diameter: 10 mm
- Inner Diameter: 10 mm
- Outer Diameter: 14 mm
- Width: 10.0 mm
- Internal Structure: Carbon Cage Type
KT101410EGB2 Material and Rated Data
What material, mass, and load ratings are provided?
The bearing material is listed as Carbon Steel, and the product introduction also refers to high carbon steel. The supplied product data includes a mass of 3.2 g, a basic dynamic load rating of 4900 N, and a basic static load rating of 4680 N.
- Bearing Material: Carbon Steel
- Mass: 3.2 g
- Basic Dynamic Load Rating: 4900 N
- Basic Static Load Rating: 4680 N
- Roller Diameter Tolerance: B2
