IKO BHAM1612
Shell Needle Roller Bearing, Inch, Caged, Chromium Molybdenum Steel, Heavy Duty, Closed End
BHAM1612 IKO Needle Roller Bearing Overview
The BHAM1612 is an IKO shell needle roller bearing in the Needle Roller Bearings product series. It is described as an inch, caged, closed-end bearing made from chromium molybdenum steel with a heavy-duty designation in the supplied product data.
What is the BHAM1612?
The BHAM1612 is a shell-type needle roller bearing with a cage-type internal structure. The listed bearing material is chromium molybdenum steel, and its category path places it under IKO needle roller bearings.
BHAM1612 Dimensions and Mass
- Shaft diameter: 25.400 mm
- Inscribed circle diameter: 25.400 mm
- Outer diameter: 33.338 mm
- Width: 19.05 mm
- Mass: 37.0 g
What dimensions are provided for the BHAM1612?
The supplied data lists a 25.400 mm shaft and inscribed circle diameter, a 33.338 mm outer diameter, and a 19.05 mm width. The product data also lists maximum width entries of 3.4 mm and 0 mm without additional interpretation.
BHAM1612 Load Ratings and Construction Details
The bearing data includes a basic dynamic load rating of 19300 N and a basic static load rating of 29700 N. Its construction is identified as caged, shell type, closed end, and chromium molybdenum steel.
What construction and load-rating information is available?
The BHAM1612 uses a cage-type internal structure and is described as a closed-end shell needle roller bearing. The stated basic dynamic and static load ratings are 19300 N and 29700 N, respectively; suitability for a particular use should be checked against the required bearing specifications.
