IKO NA4836
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA4836
Shaft Diameter
180
mm
inside dimetar
180
mm
Outer Diameter
225
mm
Width
45
mm
Width of innerring
0.000
mm
rs min.
1.1
mm
Inner Diameter
195
mm
Amount of movement
1.500
mm
da min
186.5
mm
da max
193.0
mm
da max
218.5
mm
Basic dynamic load rating
218000
N
Basic static load rating
602000
N
IR
LRT 18019545
mm
Mass
4340.0
g
