IKO NA4903UU
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, With Seals, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA4903UU
Shaft Diameter
17
mm
inside diameter
17
mm
Outer Diameter
30
mm
Width
13
mm
Width of innerring
14
mm
rs min.
0.3
mm
Inner Diameter
22
mm
da min
19.0
mm
da max
21.0
mm
da max
28.0
mm
Basic dynamic load rating
10300
N
Basic static load rating
13100
N
Type of Inner Ring
LRTZ 172214
Mass
39.5
g
