IKO NA4916UU
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, With Seals, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA4916UU
Shaft Diameter
80
mm
inside diameter
80
mm
Outer Diameter
110
mm
Width
30
mm
Width of innerring
31
mm
rs min.
1.0
mm
Inner Diameter
90
mm
da min
85.0
mm
da max
88.0
mm
da max
105.0
mm
Basic dynamic load rating
80700
N
Basic static load rating
158000
N
Type of Inner Ring
LRTZ 809031
Mass
860.0
g
