IKO NA4924UU
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, With Seals, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA4924UU
Shaft Diameter
120
mm
inside diameter
120
mm
Outer Diameter
165
mm
Width
45
mm
Width of innerring
46
mm
rs min.
1.1
mm
Inner Diameter
135
mm
da min
126.5
mm
da max
133.0
mm
da max
158.5
mm
Basic dynamic load rating
178000
N
Basic static load rating
410000
N
Type of Inner Ring
LRTZ 12013546
Mass
2990.0
g
