IKO NA4948
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA4948
Shaft Diameter
240
mm
inside dimetar
240
mm
Outer Diameter
320
mm
Width
80
mm
Width of innerring
0.000
mm
rs min.
2.1
mm
Inner Diameter
265
mm
Amount of movement
4.000
mm
da min
251.0
mm
da max
262.0
mm
da max
309.0
mm
Basic dynamic load rating
565000
N
Basic static load rating
1320000
N
IR
LRT 24026580
mm
Mass
18000.0
g
