IKO NA4976
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA4976
Shaft Diameter
380
mm
inside dimetar
380
mm
Outer Diameter
520
mm
Width
140
mm
Width of innerring
0.000
mm
rs min.
4.0
mm
Inner Diameter
430
mm
Amount of movement
5.000
mm
da min
396.0
mm
da max
427.0
mm
da max
504.0
mm
Basic dynamic load rating
1540000
N
Basic static load rating
4030000
N
IR
LRT 380430140
mm
Mass
90300.0
g
