IKO NA69/22UU
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, With Seals, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA69/22UU
Shaft Diameter
22
mm
inside diameter
22
mm
Outer Diameter
39
mm
Width
30
mm
Width of innerring
31
mm
rs min.
0.3
mm
Inner Diameter
28
mm
da min
24.0
mm
da max
27.0
mm
da max
37.0
mm
Basic dynamic load rating
33800
N
Basic static load rating
52000
N
Type of Inner Ring
LRTZ 222831
Mass
153.0
g
