IKO NA6903UU
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, With Seals, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA6903UU
Shaft Diameter
17
mm
inside diameter
17
mm
Outer Diameter
30
mm
Width
23
mm
Width of innerring
24
mm
rs min.
0.3
mm
Inner Diameter
22
mm
da min
19.0
mm
da max
21.0
mm
da max
28.0
mm
Basic dynamic load rating
19800
N
Basic static load rating
30600
N
Type of Inner Ring
LRTZ 172224
Mass
68.5
g
