IKO NA6906UU
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, With Seals, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA6906UU
Shaft Diameter
30
mm
inside diameter
30
mm
Outer Diameter
47
mm
Width
30
mm
Width of innerring
31
mm
rs min.
0.3
mm
Inner Diameter
35
mm
da min
32.0
mm
da max
34.0
mm
da max
45.0
mm
Basic dynamic load rating
40100
N
Basic static load rating
63000
N
Type of Inner Ring
LRTZ 303531
Mass
185.0
g
