IKO NA6914UU
Machined Type Needle Roller Bearings, High Carbon Steel, Oil Hole, With Seals, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NA6914UU
Shaft Diameter
70
mm
inside diameter
70
mm
Outer Diameter
100
mm
Width
54
mm
Width of innerring
55
mm
rs min.
1.0
mm
Inner Diameter
80
mm
da min
75.0
mm
da max
78.0
mm
da max
95.0
mm
Basic dynamic load rating
124000
N
Basic static load rating
281000
N
Type of Inner Ring
LRTZ 708055
Mass
1400.0
g
