IKO NAF406220
Needle Roller Bearings with Separable Cage, High Carbon Steel, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
RNAFW223026
Shaft Diameter
22
mm
Inscribed circle diameter
22
mm
Outer Diameter
30
mm
Width
26
mm
rs min.
0.3
mm
Dimension related to the installation
25.6
mm
Da max
28
mm
Dimension related to the installation
22.6
mm
Basic dynamic load rating
17500
N
Basic static load rating
30300
N
MASS
53.5
g
