IKO TAF253320/SG
Machined Type Needle Roller Bearings, High Carbon Steel, With Solid Lube
(BRAND)：IKO
(Availability)：In Stock
Order number
TAF253320/SG
Shaft Diameter
25
mm
Inner Diameter
25
mm
Outer Diameter
33
mm
Width
20
mm
rs min.
0.3
mm
Da max
31.0
mm
Basic dynamic load rating
20000
N
Basic static load rating
32100
N
Mass
43.5
g
The IKO TAF253320/SG Is a Needle Roller Bearing
What type of bearing is the TAF253320/SG?
The TAF253320/SG is an IKO needle roller bearing listed in the Needle Roller Bearings product series. It is described as a machined type needle roller bearing with a cage-type internal structure.
- Brand: IKO
- Model: TAF253320/SG
- Bearing type: Needle Roller Bearings
- Internal structure: Cage Type
The TAF253320/SG Has Defined Bore, Outer Diameter, and Width
What dimensions and load values are provided for this bearing?
The supplied product data lists the following specifications for the TAF253320/SG:
- Shaft diameter: 25 mm
- Inner diameter: 25 mm
- Outer diameter: 33 mm
- Width: 20 mm
- rs minimum: 0.3 mm
- Da maximum: 31.0 mm
- Basic dynamic load rating: 20,000 N
- Basic static load rating: 32,100 N
- Mass: 43.5 g
The TAF253320/SG Uses High Carbon Chrome Steel With Solid Lube
What material and lubrication details are included in the product data?
The bearing material is listed as High Carbon Chrome Steel, and the product description identifies High Carbon Steel construction with Solid Lube. The order number for this part is TAF253320/SG, and it is categorized under Brand > IKO > Needle Roller Bearings.
- Confirm the shaft, housing, and clearance requirements against the listed 25 mm inner diameter, 33 mm outer diameter, and 20 mm width.
- Review the 0.3 mm minimum corner-radius and 31.0 mm maximum Da values where relevant to installation.
- Use the stated material and solid-lube description to compare this part with other needle roller bearings.
