IKO TAFI102220
Machined Type Needle Roller Bearings, High Carbon Steel, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
Order Number
TAFI102220
Shaft Diameter
10
mm
inside dimetar
10
mm
Outer Diameter
22
mm
Width
20
mm
Width of innerring
0.000
mm
rs min.
0.3
mm
Inner Diameter
14
mm
Amount of movement
0.500
mm
da min
12.0
mm
da max
13.0
mm
da max
20.0
mm
Basic dynamic load rating
14800
N
Basic static load rating
18600
N
IR
LRT 101420
mm
Mass
38.0
g
