IKO TAFI223416
Machined Type Needle Roller Bearings, High Carbon Steel, Inner Ring
(BRAND)：IKO
(Availability)：In Stock
Order Number
TAFI223416
Shaft Diameter
22
mm
inside dimetar
22
mm
Outer Diameter
34
mm
Width
16
mm
Width of innerring
0.000
mm
rs min.
0.3
mm
Inner Diameter
26
mm
Amount of movement
0.500
mm
da min
24.0
mm
da max
25.0
mm
da max
32.0
mm
Basic dynamic load rating
16300
N
Basic static load rating
24900
N
IR
LRT 222616
mm
Mass
52.0
g
